The TAOS® range of aluminium profiles is designed for the fabrication of sliding aluminium shutters. This range of sliding shutters can also be incorporated into a Wallis& Outdoor® pergola. Extra options : motorisation and a 25mm solid insulated slat.

Taos® Aluminum Sliding Shutter

Very comtemporary models with optional motorisation

Hightlights

  • Very wide choice of models
  • Design of sections and molded pieces
  • Can be adapted to large-scale openings
  • Can be incorporated into a Wallis& Outdoor® pergola
  • Two types of roller guide to support 40 or 80kg/leafs
  • Motorisation possible
  • Available in hinged version.
  • Available in all colors Profils Systèmes'
  • Colour shades guaranteed up to 25 years

Thermal Performances

  • The shutter with  thermal insulation blades allows obtaining a R of 0.27 m².K/W (BEB3.9.0056.2 of CEBTP).

View our photo book

View online

Max. dimensions

  • H2500 x W2000 mm ou H3000 x W1500 mm with truck slider I (max. load 80 kg)
  • H 2300 x W 1000 mm with truck sliders II (max. load 40 kg)
  • Large dimensions up to 8 metres : 4 leaves, 2 rails

Models

  • Solid with vertical slats
  • Solid with thermal bridge break
  • Shading louvers
  • Open louvers
  • Adjustable louvers
  • Multi directional lovers – height 100 mm

Weight per leaf

  • Up to 80 kg

Max. dimensions

  • H2500 x W2000 mm ou H3000 x W1500 mm with truck slider I (max. load 80 kg)
  • H 2300 x W 1000 mm with truck sliders II (max. load 40 kg)
  • Large dimensions up to 8 metres : 4 leaves, 2 rails

Models

  • Solid with vertical slats
  • Solid with thermal bridge break
  • Shading louvers
  • Open louvers
  • Adjustable louvers
  • Multi directional lovers – height 100 mm

Weight per leaf

  • Up to 80 kg

Technical details

Opening sections

  • 2 systems :
    • Edging
    • Straight cut
  • Tubular:
    • 62 x 33 mm for louvred or mixed shutters
    • Section variation for 100mm: upright 66 x 33mm (only for straight-cut monorail)

Assembly

  • The opening panels are retained with barbed fixings and adhesive.
  • All fixings are stainless steel or aluminium.
  • All fittings and mounting brackets are invisible

Locking

The shutters can be locked by either :

  • a bolt
  • a 2 or 3-point lock

Options

  •  Identical covers for motorized and manual versions.
  • Operation by remote control or switch
  • Compatible with TOR, GTC, GTB or Domotique operating systems
  • Automatic stop to prevent pinched fingers
  • Integrated pre-alarm
  • Electric locking available
